Interdisciplinary Faculty of Science and Engineering, Shimane University
Fujiwara and Manago laboratory

Instruments

Last update: 2022-06

We mainly perform low-temperature nuclear magnetic resonance (NMR) measurements with a high-pressure technique. Belows are our research instruments.

NMR spectrometers

No. 1

This was for low-frequency (1–50 MHz) NMR measurements and has retired.

NMR spectrometer
NMR spectrometer. This is not used today.

No. 2

This is specialized for zero-field NQR measurements and is used for low temperature measurements down to 4 K combined with a GM cooler. The spectrometer is applicable for a wide frequency range of 3–400 MHz, but we now (in 2022) mainly use it for lower-frequency measurements (about 3–20 MHz). We have recently succeeded in measuring a spectrum above 30 MHz using a newly-developed higher-frequency NQR probe.

NMR spectrometer
NMR spectrometer for zero-field measurements.

No. 3

This is the main NMR instrument in our laboratory. This is used for NMR measurements upto 9 T and down to 2 K using Physical Properties Measurement System (PPMS) by Quantum Design.

NMR spectrometer
NMR spectrometer.
PPMS and NMR probe
PPMS Dewar and an NMR probe.

Refrigerators

GM cooler

This is the 4 K Gifford-McMahon (GM) cooler by Sumitomo Heavy Industries, and the lowest temperature is about 3 K. This refrigerator can operate using only electricity and water (without He supply). We at first suffered from the temperature oscillation with the amplitude of 0.2 K, but this has been improved after various efforts. This is used for NQR measurements and pressure calibration.

GM cooler and NMR spectrometer
GM cooler (right) and an ac susceptibility measurements system (left).

Instruments for pressure application

Indenter-type cells

They are main pressure cells in our laboratory. We have small (max. 4.8 GPa) and large (max. 4.2 GPa) pressure cells.

Two indenter cells
Indenter cells.

Opposed-type anvil cell

Maximum pressure is about 6 GPa.

opposed-type anvil cell
Parts of the opposed-type anvil cell.

Manipulator

It consists of an optical microscope and needles for setting high pressure cell.

Optical microscope
Optical microscope.

Coil manufacturing system

It consists of a microscope, motor, bobbin holder, and a rod to make an NMR coil.

Coil manufacturing system
Coil manufacturing system.

10-ton press

It is used to produce the pressure of cells.

press
Press.

Cutter

This is mainly used for cutting a Ni-Cr-Al alloy rod for the pressure cell parts.

cutter
Cutter.

Machine tools

Desktop lathe

This is a product of Sakai Machine Tool (ML-360). It is a small and easy-to-use machine. This is used to make parts of pressure cells.

desktop lathe
Desktop lathe.

Lathe

This large desktop lathe is a product of Cosmo Kikai. This machine has been installed in the machine room of the faculty.

lathe
Large lathe.

Milling machine

This large desktop milling machine is a product of Cosmo Kikai.

milling machine
Large milling machine.
